Stainless Steel Wire Mesh

Product Name:

Stainless Steel Wire Mesh

Specifications For Stainless Steel Wire Mesh

Stainless Steel Wire Mesh
Width:1meter
Length:30meters
Tchnique:plain weave twill weave dutch weave
Material:304 316 316L

Stainless Steel Wire Mesh

Material: 304 310 316 316L 410
Wire Diameter:0.025-6mm
Mesh size:1-1000mesh

STAINLESS STEEL WIRE MESH:

Material:sus302,304,304L,316,316L SS wire

Weaving:Plain,Twill,Dutch

Features:Acid resistant,alkali resistant,heart resistant,corrosion resistant.

Packing:Inside with kraft paper and outside wrap with PVC woven bag

Sizes:Standard roll width: 1m to 48".Standard roll length of stainless steel wire mesh: 30m to 100".

Applications: Stainless steel wire mesh made from choice wires are used for separation of solids and clear filtration of liquids, as in the cleaning of fuels or hydraulic liquids, or in water treatment.

Stainless Steel Wire Mesh Specification:

Mesh/Inch	Wire Diameter		Aperture		Open Area	Weight(LB) /100 Square Foot
Mesh/Inch	Inch	MM	Inch	MM	Open Area	Weight(LB) /100 Square Foot
1x1	0.080	2.03	0.920	23.37	84.6	41.1
2X2	0.063	1.60	0.437	11.10	76.4	51.2
3X3	0.054	1.37	0.279	7.09	70.1	56.7
4X4	0.063	1.60	0.187	4.75	56.0	104.8
5X5	0.041	1.04	0.159	4.04	63.2	54.9
10X10	0.025	0.64	0.075	1.91	56.3	41.2
24X24	0.014	0.356	0.0277	0.70	44.2	31.8
80X80	0.0055	0.140	0.0070	0.18	31.4	16.9
90X90	0.005	0.127	0.0061	0.16	30.1	15.8
100X100	0.0035	0.089	0.0065	0.17	42.3	8.3
120X120	0.0037	0.0940	0.0064	0.1168	30.7	11.6
160X160	0.0025	0.0635	0.0038	0.0965	36.4	5.94
200X200	0.0021	0.0533	0.0029	0.0737	33.6	6.2

Production Machine For Stainless Steel Wire Mesh

Project Photo For Stainless Steel Wire Mesh
